CENTURIO PRO 6 Channel Controller for pH/ORP, CL2/CLO2/O3, NTU/DO/EC/Temp

  • 6 Parameter Multi Function Controller
  • Plug and Play – Any combination of variables possible (pH, ORP, EC, CL2, CLt, NTU, DO, mA).
  • Example of configuration: 3 x pH channels, 2 x ORP, 1 x NTU
  • Amperometric sensor & Inductive Conductivity Sensor cards available
  • Can scale and control external mA input, e.g. mA converted to Pressure
  • Relay (ON/OFF or PWM) or Pulse Proportional Control
  • 2 x Water meter inputs to log flow rate and consumption
  • Touchscreen
  • ERMES Ready – Remote access via 4G, WiFi, Ethernet with live readings
  • MODBUS RTU or TCP, 4-20mA
Compare
SKU: EMEC CENTP Category: Tag: Brand:

Description

Pyxis Lab Sensors Product banner
Superseded
EMEC CENTURIO Brochure 2019
EMEC CENTURIO Pro & Pool Instruction Manual R28-08-22 LR
EMEC CENTURIO Pro Data Sheet R3-06-20
Superseded
EMEC CENTURIO Brochure 2019
EMEC CENTURIO Pro & Pool Instruction Manual R28-08-22 LR
EMEC CENTURIO Pro Data Sheet R3-06-20
Name
Superseded

Additional information

Variables Measured

CLt, Cl2, CLO2, Conductivity, DO, Flow Status, Flow Volume, H2O2, ORP, pH, TDS, Temperature

Inputs

Amperometric Sensor, Conductivity Probe with Electrodes & PT100, DO Sensor, Flow Switch Contact, Inductive Conductivity Probe & PT100, ORP Probe, pH Probe, PT100, Standby Dry Contact, Turbidity Sensor, Water Meter Bleed Pulses, Water Meter Make-up Pulses

Outputs

4-20mA, Alarm Relay, Optional Modbus, Pulse, Switched Relays For Optional Pumps/Valves

Remote Comms

4G, LAN (ethernet), Modbus RTU/TCP

IP Rating

IP65
